N7k Series

Item

Specification

Cisco Nexus 7700 2-Slot Chassis

Cisco Nexus 7700 6-Slot Switch

Cisco Nexus 7700 10-Slot Switch

Cisco Nexus 7700 18-Slot Switch

Port count

48 x 10 Gbps, 24 x 40 Gbps, and 12 x 100 Gbps

192 x 10 Gbps, 96 x 40 Gbps, and 48 x 100 Gbps

384 x 10 Gbps, 192 x 40 Gbps, and 96 x 100 Gbps

768 x 10 Gbps, 384 x 40 Gbps, and 192 x 100 Gbps

Product compatibility

●  Supports all Cisco Nexus 7700 switch modules except the following:

◦  N77-F248XP-23E

●  Does not use fabric modules

●  Supports all Cisco Nexus 7700 Series Supervisor and I/O modules

●  Supports Cisco Nexus 7700 Series Fabric-2 modules

●  Supports Cisco Nexus 7700 Series Fabric 3 modules

●  Supports all Cisco Nexus 7700 Series Supervisor and I/O modules

●  Supports Cisco Nexus 7700 Series Fabric-2 modules

●  Supports Cisco Nexus 7700 Series Fabric 3 modules

●  Supports all Cisco Nexus 7700 Series Supervisor and I/O modules

●  Supports Cisco Nexus 7700 Series Fabric-2 modules

Software compatibility

Cisco NX-OS Software Release 7.2 or later

Cisco NX-OS Software Release 6.2.6 or later

Cisco NX-OS Software Release 6.2.2 or later

Cisco NX-OS Software Release 6.2.2 or later

Options

●  Door air filter

●  Lockable front module doors

●  Door air filter

●  Lockable front module doors

●  Door air filter

●  Lockable front module doors

●  Door air filter

●  Lockable front module doors

●  Power supply center cable management

System forwarding capacity

No fabric modules

All I/O modules are line rate

21 Tbps

42 Tbps

83 Tbps

Max local switching capacity^*

2.4 Tbps

2.4 Tbps

2.4 Tbps

1.2 Tbps

Max inter-slot switching capacity^*

n/a

2.4 Tbps

2.4 Tbps

1.2 Tbps

Reliability and availability

Online insertion and removal (OIR) of redundant power supplies

OIR of all redundant components: supervisor and fabric modules, power supplies, and fan trays

OIR of all redundant components: supervisor and fabric modules, power supplies, and fan trays

OIR of all redundant components: supervisor and fabric modules, power supplies, and fan trays

MIBs

Supports Simple Network Management Protocol Version 3 (SNMPv3), v2c, and v1 (see Cisco NX-OS Software release notes for details about specific MIB support)

Supports SNMPv3, v2c, and v1 (see Cisco NX-OS Software release notes for details about specific MIB support)

Supports SNMPv3, v2c, and v1 (see Cisco NX-OS Software release notes for details about specific MIB support)

Supports SNMPv3, v2c, and v1 (see Cisco NX-OS Software release notes for details about specific MIB support)

Network management

Cisco Data Center Network Manager (DCNM)

Cisco Data Center Network Manager (DCNM)

Cisco Data Center Network Manager (DCNM)

Cisco Data Center Network Manager (DCNM)

Programming interfaces

●  XML

●  Scriptable command-line interface (CLI)

●  Cisco DCNM web services

●  Python

●  Tool Command Language (TCL)

●  Cisco IOS ^® Embedded Event Manager (EEM)

●  Cisco One Platform Kit (OnePK ^™)

●  OpenFlow

●  XML

●  Scriptable CLI

●  Cisco DCNM web services

●  Python

●  TCL

●  Cisco IOS EEM

●  Cisco OnePK

●  OpenFlow

●  XML

●  Scriptable CLI

●  Cisco DCNM web services

●  Python

●  TCL

●  Cisco IOS EEM

●  Cisco OnePK

●  OpenFlow

●  XML

●  Scriptable CLI

●  Cisco DCNM web services

●  Python

●  TCL

●  Cisco IOS EEM

●  Cisco OnePK

●  OpenFlow

Physical specifications

●  Required rack space: 3RU

●  2-slot switch: 1 dedicated supervisor module and 1 I/O module

●  No fabric modules

●  2 power supply slots

●  Dimensions (H x W x D): 5.15 x 17.3 x 29.1 in. (13.08 x 43.9 x 73.9 cm)

●  Chassis depth, including cable management and chassis doors, is 35.1 in. (89.15 cm)

●  Unit is rack-mountable in a standard 19-inch (482.6-mm) EIA rack; unit is also 2-post rack-mountable

●  Weight

◦  Chassis only: 37.5 lb (17 kg)

◦  Fan Tray: 13.5 lb (6.1 kg)

●  Supports 3-kW AC and DC and 3.5-kW HV AC/DC power supplies

●  Required rack space: 9RU

●  6-slot switch: 2 dedicated supervisor modules and 4 I/O modules

●  6 fabric module slots

●  4 power supply slots

●  Dimensions (H x W x D): 15.6 x 17.3 x 32 in. (39.62 x 43.9 x 81.3 cm)

●  Chassis depth, including cable management and chassis doors, is 38 in. (96.52 cm)

●  Additional depth with Generation 2 fan tray is 1.75 in. (4.5 cm)

●  Unit is rack-mountable in a standard 19-inch (482.6-mm) EIA rack; unit is also 2-post rack-mountable

●  Weight

◦  Chassis only: 145 lb (65.8 kg)

◦  Fabric Module: 5.6 lb (2.5 kg)

◦  Fan Tray: 5.3 lb (2.4 kg)

◦  Fan Tray (Generation 2): 7.75 lb (3.5 kg)

●  Supports 3-kW AC and DC and 3.5-kW HV AC/DC power supplies

●  Required rack space: 14RU

●  10-slot switch: 2 dedicated supervisor modules and 8 I/O modules

●  6 fabric module slots

●  8 power supply slots

●  Dimensions (H x W x D): 24.35 x 17.3 x 34 in. (61.85 x 43.9 x 86.4 cm)

●  Chassis depth, including cable management and chassis doors, is 40 in. (101.6 cm)

●  Additional depth with Generation 2 fan tray is 1.75 in. (4.5 cm)

●  Unit is rack-mountable in a standard 19-inch (482.6-mm) EIA rack

●  Weight

◦  Chassis only: 160 lb (72.6 kg)

◦  Fabric Module: 11 lb (5.0 kg)

◦  Fan Tray: 8.5 (3.9 kg)

◦  Fan Tray (Generation 2): 12 lb (5.4 kg)

●  Supports 3-kW AC and DC and 3.5-kW HV AC/DC power supplies

●  Required rack space: 26RU

●  18-slot switch: 2 dedicated supervisor modules and 16 I/O modules

●  6 fabric module slots

●  16 power supply slots

●  Dimensions (H x W x D): 45.25 x 17.3 x 35 in. (114.9 x 43.9 x 88.9 cm)

●  Chassis depth, including cable management and chassis doors, is 41 in. (104.1 cm)

●  Additional depth with Generation 2 fan tray is 1.75 in. (4.5 cm)

●  Unit is rack-mountable in a standard 19-inch (482.6-mm) EIA rack

●  Weight

◦  Chassis only: 300 lb (136.0 kg)

◦  Fabric Module: 20 lb (9.1 kg)

◦  Fan Tray: 13.5 lb (6.1 kg)

◦  Fan Tray (Generation 2): 17.75 lb (8.1 kg)

●  Supports 3-kW AC and DC and 3.5-kW HV AC/DC power supplies

Environmental specifications

●  Airflow direction: Front to back

●  Operating temperature: 32 to 104°F (0 to 40°C)

●  Operational relative humidity: 5 to 90%, noncondensing

●  Operating altitude: -500 to 13,123 ft. (agency certified 0 to 6500 ft.)

●  Seismic: Zone 4 per GR63

●  Floor loading: 24 lbs per sq. ft.

●  Operational vibration

●  GR63, Section 5.4.2

●  ETS 300 019-1-3, Class 3.1, Section 5.5

●  Storage altitude: -1000 to 30,000 ft.

●  Storage temperature: -40 to 158°F (-40 to 70°C)

●  Storage relative humidity: 5 to 95%, noncondensing

●  Heat dissipation: Maximum 6650 BTUs per hour (actual dissipation will be lower, depending on the chassis configuration)

●  Airflow direction: Front to back

●  Operating temperature: 32 to 104°F (0 to 40°C)

●  Operational relative humidity: 5 to 90%, noncondensing

●  Operating altitude: -500 to 13,123 ft. (agency certified 0 to 6500 ft.)

●  Seismic: Zone 4 per GR63

●  Floor loading: 92 lbs per sq. ft.

●  Operational vibration

●  GR63, Section 5.4.2

●  ETS 300 019-1-3, Class 3.1, Section 5.5

●  Storage altitude: -1000 to 30,000 ft.

●  Storage temperature: -40 to 158°F (-40 to 70°C)

●  Storage relative humidity: 5 to 95%, noncondensing

●  Heat dissipation: Maximum 26,280 BTUs per hour (actual dissipation will be lower, depending on the chassis configuration)

●  Airflow direction: Front to back

●  Operating temperature: 32 to 104°F (0 to 40°C)

●  Operational relative humidity: 5 to 90%, noncondensing

●  Operating altitude: -500 to 13,123 ft. (agency certified 0 to 6500 ft.)

●  Seismic: Zone 4 per GR63

●  Floor loading: 122 lbs per sq. ft.

●  Operational vibration

●  GR63, Section 5.4.2

●  ETS 300 019-1-3, Class 3.1, Section 5.5

●  Storage altitude: -1000 to 30,000 ft.

●  Storage temperature: – 40 to 158°F (-40 to 70°C)

●  Storage relative humidity: 5 to 95%, noncondensing

●  Heat dissipation: Maximum 52,500 BTUs per hour (actual dissipation will be lower, depending on the chassis configuration)

●  Airflow direction: Front to back

●  Operating temperature: 32 to 104°F (0 to 40°C)

●  Operational relative humidity: 5 to 90%, noncondensing

●  Operating altitude: -500 to 13,123 ft. (agency certified 0 to 6500 ft.)

●  Seismic: Zone 4 per GR63

●  Floor loading: 230 lbs per sq. ft.

●  Operational vibration

●  GR63, Section 5.4.2

●  ETS 300 019-1-3, Class 3.1, Section 5.5

●  Storage altitude: -1000 to 30,000 ft.

●  Storage temperature: -40 to 158°F (-40 to 70°C)

●  Storage relative humidity: 5 to 95%, noncondensing

●  Heat dissipation: Maximum 96,160 BTUs per hour (actual dissipation will be lower, depending on the chassis configuration)

Regulatory compliance

●  EMC compliance

●  FCC Part 15 (CFR 47) (USA) Class A

●  ICES-003 (Canada) Class A

●  EN55022 (Europe) Class A

●  CISPR22 (International) Class A

●  AS/NZS CISPR22 (Australia and New Zealand) Class A

●  VCCI (Japan) Class A

●  KN22 (Korea) Class A

●  CNS13438 (Taiwan) Class A

●  CISPR24

●  EN55024

●  EN50082-1

●  EN61000-3-2

●  EN61000-3-3

●  EN61000-6-1

●  EN300 386

Environmental standards

●  NEBS criteria levels ^*

◦  SR-3580 NEBS Level 3 (GR-63-CORE and GR-1089-CORE)

●  Verizon NEBS compliance ^*

◦  Telecommunications Carrier Group (TCG) checklist

●  Century Link NEBS requirements ^*

◦  Telecommunications Carrier Group (TCG) checklist

●  ATT NEBS requirements ^*

◦  ATT TP76200 level 3

●  ETSI ^*

◦  ETSI 300 019-2-1, Class 1.2 storage

◦  ETSI 300 019-2-2, Class 2.3 transportation

◦  ETSI 300 019-2-3, Class 3.2 stationary use

^* Validation in progress

Safety

●  UL/CSA/IEC/EN 60950-1

●  AS/NZS 60950
